33' TOURNAMENT Edition

The Ultimate live Bait Fishing Machine

The Onslow Bay 33′ Tournament Edition is designed to handle either twin or triple engine configurations depending on the wants and needs of the customer. It is intended to be the ultimate offshore live bait fishing machine with a standard 45 gallon round live bait well in the transom and the option for either a 45 gallon leaning post live well or a 73 gallon leaning post live well. It features a one level deck with 6 insulated below deck fish/storage boxes. There is a choice of consoles with the first having a front entry door, and the second with a side entry door and cooler seat forward.

The ride of the 33′ is something that has to be experienced to appreciate. We took all of the strengths of the 27′ and incorporated those on the 33′, just in a much larger platform. If you are ready for the next greatest thing in offshore center console boats, call us today to schedule a sea trial. You will not be disappointed.

Centerline LOA: 32’10”
Waterline Length: 27’6
Beam: 9’11”
Deadrise: 24 degrees
Dry Weight: 7000 lbs
Draft: 28″
Max HP: 1200 Twins or Triples
Min HP: 600
Max Eng Weight: 2100 lbs
Min Cockpit Depth: 24″
Fuel Capacity: 350/300 gallons
Max Speed: TBD
Rod Holder Layout
Boat Test – 300 V8
Boat Test – 400 M

boat illustration

STANDARD FEATURES

  • All foam core construction (no wood no rot)
  • Insulated 500 quart forward fish box with 2 lids and divider 70”L x 29”W x 18”D
  • 350 gallon fuel tank with corrosion resistant finish that is foamed and fiberglassed into place. If you have a step down in the console then fuel capacity is 300 gallons
  • Positive life ventilated step hull with a 48 degree entry and a 24 deadrise at the transom
  • All structural bonding done with Plexus® specialty adhesives
  • Insulated 240 quart forward cooler box 22”L x 31”W x 21”D
  • Large Console with 125 qt cooler seat, side entry and Integrated Footrest
  • 7 degree reverse chine and large flare for a dry ride
  • Vinyl ester resin skin coat in hull to prevent blistering
  • (2) Insulated 230 quart side fish boxes amid ship 55”L x 18”W x 14”D
  • Aluminum T-top with LED spreader lights, life jacket holder, rod holders, and electronics box
  • Full length running surface
  • All areas except for bilge and fish boxes are foam filled
  • (2) Insulated 230 quart side fish boxes in the cockpit 55”L x 18”W x 14”D
  • (4) 30 degree gunnel mount Gemlux® rod holders
  • Lenco® electro polished stainless steel extreme duty 12 x 18 trim tabs with indicator lights and auto retract
  • Ritchie® flush mount compass installed on dash
  • All hatches use stainless steel piano hinge and Gemlux® 2.5” stainless steel compression latches
  • Boarding ladder
  • Uflex® hydraulic steering with tilt helm and heavy duty cylinder
  • (2) Rule® 1500 gph bilge pumps with internal float switches
  • All doors are King Starboard®, back screwed for appearance, and use Gemlux® stainless steel slam latches
  • Recessed aluminum bow rail
  • Dual fuel fills
  • Accon Marine® stainless steel pop up bow light
  • Completely self bailing deck with (2) stainless steel deck drains with built in check valves
  • One level deck with gutter system for drainage
  • Starboard flush mount electronics cabinet with clear hideaway door
  • (6) Accon Marine® 8” pop up stainless steel cleats
  • 45 gallon round transom livewell with Carolina blue interior, clear plexi-glass lid and (2) 800 gph Shurflo® Tournament series pumps
  • 3 piece hull, cap, and liner “fisherman friendly” design

SPECS

View full list of Onslow Bay Boatworks 33′ Tournament Edition Prices for all customization options. (PDF Download)

OPTIONS

APPEARANCE & UTILITY

  • Plumbed in head with holding tank underneath
  • Powder coating T-top
  • Freshwater Washdown
  • Mate Series Rod holders
  • Additional Gemlux Rod Holders
  • Cockpit Bolsters
  • 3 Bank battery charger
  • Custom Hull Color
  • Powder Coating on Backrest
  • Powder Coating on Rear Seats

SEATING

  • Flip down seats in cockpit
  • Rear Seats
  • Tackle Center
  • 73 Gallon Leaning post/ livewell with rear bench seat
  • 45 Gallon leaning post/livewell

    T-TOP and Console

    • Taco Outriggers with 15’ retractable poles
    • T-top Wings
    • T-top Curtains
    • Bi Colored LED Flush Map Lights
    • Bi Colored LED Map Light Tube
    • Fiberglass Hardtop

    TRAILER

    • Air tight hubs
    • Electric over hydraulic brakes
    • Mag Wheels
    • C-Channel
    • AmeraTrail tandem axle trailer with brakes and Stainless Steel calipers
